5KWh Lithium Iron Phosphate Battery
Main Parameter
Rated Power
5.22Kwh
Cell Type
LFP
Cell Quantity
16
Rated Voltage
51.2V
Voltage Range
44.8~57.6V
Charging Current
50A
Discharging Current
100A
Dimensions
680*450*160mm
Weight
49kg
Communication Protocol
CAN 485
Protection Level
IP65
Working Temperature
-10 ~ 55C
Relative humidity
5% ~ 95%
Cooling method
Natural cooling
Installation model
Ground/Wall-Mounted
Design Life
15 years
Certificate
IEC62619 CE RHOS MDS
Matched Inverter
SMA/Growatt/Deye, etc
Load
Air Conditioning, Refrigerator, fan, TV, water, heater etc.
